Efficient power chain: By optimizing and matching the engine, transmission, and drive axle, lower fuel consumption and higher transportation efficiency can be achieved.
Vehicle stability control system: improves the driving stability and safety of vehicles under various road conditions.
Comfortable cab: Provides spacious driving space, excellent sound insulation, and humanized interior design to ensure driver comfort and convenience.
Advanced in vehicle information technology: optional vehicle networking system to achieve remote monitoring, data analysis, and intelligent scheduling functions, improving logistics efficiency.
driver license: | A2 | Announcement Model: | ZZ4257V424KF1L |
Drive type: | 6X4 | Wheelbase: | 3800+1400mm |
engine: | Weichai WP15NG530E61 | Gearbox: | 12-speed gearbox |
Rear axle ratio: | 3.545 | Body length: | 7.615 m |
Body width: | 2.53 m | Ride height: | 3.82 m |
Front track: | 1996mm | Rear track: | 1830/1830mm |
Vehicle weight: | 8.8 tons | Total mass: | 25 tons |
Total traction mass: | 40 tons | Maximum speed: | 89km/h |
Origin: | Shandong | Tonnage level: | Heavy Truck |
Fuel Type: | Liquefied Natural Gas (LNG) |
|
|
Engine parameters |
|
|
|
engine model: | Weichai WP15NG530E61 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | Liquefied Natural Gas (LNG) |
Cylinder arrangement: | In-line | Displacement: | 14.6L |
Emission Standards: | National VI | Maximum horsepower: | 530 hp |
Maximum output power: | 390kW | Maximum Torque: | 2500N.m |
Maximum torque speed: | 950-1350rpm | Rated speed: | 1700rpm |
Cab parameters |
|
|
|
Number of passengers allowed: | 2 people | Number of Seat Rows: | Half row |
Gearbox parameters |
|
|
|
Gearbox Model: | 12-speed gearbox | Shifting method: | Manual |
Forward gears: | 12 gears | Reverse gear number: | 2 |
Chassis parameters |
|
|
|
Permissible load on front axle: | 7000kg | Permissible load on rear axle: | 18000(two-axle group)kg |
Speed: | 3.545 | Number of springs: | 2月3日 |
tire |
|
|
|
Number of tires: | 10 | Tire specifications: | 12R22.5 18PR |
