Powerful system: Equipped with a 400 horsepower engine, it can provide powerful power output, ensuring that the vehicle can still operate efficiently under heavy loads.
Advanced suspension system: Adopting multi leaf spring suspension, it not only ensures the vehicle's load-bearing capacity but also improves ride comfort.
High strength frame and body structure: High strength steel is used to ensure the vehicle has high load-bearing capacity and durability.
Good handling performance: Equipped with advanced steering and suspension systems, the vehicle can maintain stable driving performance under different road conditions.
Safety: Equipped with excellent braking performance and anti lock braking system (ABS), it improves the safety of vehicle operation.
driver license: | A1,A2,B2 | Announcement Model: | ZZ3257V434GF1 |
Drive type: | 6X4 | Wheelbase: | 4325+1350mm |
engine: | Weichai WP10H400E62 | Gearbox: | Sinotruk HW19712CL |
Rear axle ratio: | 5.92 | Body length: | 9.32 m |
Body width: | 2.55 m | Ride height: | 3.45 m |
Front track: | 2022mm | Rear track: | 1860/1860mm |
Vehicle weight: | 12.5 tons | Rated load: | 12.37 tons |
Total mass: | 25 tons | Tonnage level: | Heavy Truck |
Approach Angle: | 17 degrees | Departure angle: | 32 degrees |
Origin: | Shandong Jinan | Market segments: | Urban construction waste |
Version: | Standard weight | Fuel Type: | diesel fuel |
Engine parameters |
|
|
|
engine model: | Weichai WP10H400E62 | Engine Brand: | Weichai |
Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
Displacement: | 9.5L | Emission Standards: | National VI |
Maximum horsepower: | 400 hp | Maximum output power: | 294kW |
Maximum Torque: | 1900N路m | Maximum torque speed: | 1200-1300rpm |
Rated speed: | 1900rpm | Engine Type: | In-line, direct injection, water-cooled, four-stroke, supercharged and intercooled, electronically controlled high-pressure common rail, Hi+SCR |
Cargo box parameters |
|
|
|
Length of cargo box: | 6.3 m | Cargo box width: | 2.35 m |
Cargo box height: | 1.5 m | Cargo box form: | Self-unloading |
